Gapping measurement sensor for HV connector

This invention describes a high-voltage cable with a sensor integrated into its end, where it connects to a high-voltage device. The sensor measures the compression force or movement at the connection point when a clamping collar secures it, helping to ensure a reliable electrical contact. The claims specify the sensor can be a simple on/off type or a more advanced one that measures the exact force or displacement.

Why it matters: Sensor miniaturization and cost have significantly improved since 2012, making integrated smart components more feasible. The increased focus on smart grid reliability and predictive maintenance now values real-time condition monitoring in high-voltage infrastructure.

Status: ExpiredProtection ended and was never renewed
How hard to build: SpecializedCustom sensor integration, high-voltage insulation, robust mechanics
