Antenna and electronic device comprising same

This invention describes a multi-layered antenna designed for high-speed 5G and 6G wireless communication. It works by arranging multiple insulating dielectric pieces between a layer with openings and a layer holding the actual antenna elements. Each antenna element sits on one side of its corresponding dielectric piece.

Why it matters: Filed as 5G deployment accelerated, the need for compact, high-frequency antenna arrays for mobile devices (H01Q1/243, H01Q3/46) has intensified. This multi-layer design could address space constraints for advanced beamforming in current 5G and emerging 6G applications.

Status: Not in forceListed as no longer active. The specific reason is not in the record we hold.
How hard to build: SpecializedCustom antenna elements, multi-layer fabrication, specific dielectrics.
