Patent drawing for Robot-based automation system for cryogenic crystal sample mounting
US 20,040,187,515 A1
Robotics US 20,040,187,515 A1 Expired

Robot-based automation system for cryogenic crystal sample mounting

A robotic system designed to precisely handle tiny, frozen crystal samples for scientific analysis, like X-ray crystallography. It uses a robot arm with a special gripper that has long, slender fingers equipped with sensors to detect how much force it's applying. This allows it to gently pick up and position samples without damaging them or letting them warm up, even in tight spaces, while also managing a container of liquid nitrogen to keep the samples cold and prevent ice buildup.

Why it matters: Since 2004, advancements in miniaturized force sensors, haptic feedback systems, and precision robotics have made the delicate, force-controlled gripping described more robust and achievable. Modern additive manufacturing could also simplify the complex finger design and integrated cooling.

Status
ExpiredProtection ended and was never renewed
How hard to build
SpecializedCustom precision gripper, cryogenic control, robot integration
