Drive mechanism for automated footwear platform

This invention describes the internal motor system for an automatic shoelace tightener. It uses a small motor connected to a gearbox, which then drives a special screw-like 'worm drive'. This worm drive slides onto a shaft from the gearbox and turns a gear that winds up the shoelace spool, tightening the shoe. The claims specifically detail how the worm drive connects and how the lace spool is designed.

Why it matters: The core mechanical components described have not seen significant technological shifts since 2019. The primary challenges of integrating a durable, lightweight, and long-lasting power source into footwear for such a mechanism likely persist.

Status: Not in forceListed as no longer active. The specific reason is not in the record we hold.
How hard to build: ModerateGear motor, worm drive, custom housing, control electronics.
