Patent drawing for Camera module capable of wide-angle shooting normal-angle shooting and mobile terminal having the same
US 10,791,274 B2
Optics US 10,791,274 B2 Expired

Camera module capable of wide-angle shooting normal-angle shooting and mobile terminal having the same

This invention describes a camera module for mobile phones that can switch between wide-angle and normal-angle views. It uses a main lens that can change its zoom, and a second lens positioned below it that automatically corrects for image distortions from the main lens, adjusting its correction based on the zoom level. The module also includes a controller and an image sensor, and may use an actuator to keep the lenses perfectly aligned.

Why it matters: Filed before fluid lens technology was mature enough for mass production. Advances in micro-actuators and fluid lens manufacturing since 2015 could now make this complex optical system feasible for mobile devices.

Status
ExpiredProtection ended and was never renewed
How hard to build
SpecializedMiniaturized variable lenses, actuators, optical design, controller.
